Webco Enclosed Side Wall Utility Truck Trailer for Container and Bulk Cargo Transport

Product Categories
HENAN FOCUS VEHICLES CO.,LTD.
Contact Now

Webco Enclosed Side Wall Utility Truck Trailer for Container and Bulk Cargo Transport

Model NO. : FZCZ9400TJZHJ

Load Capacity : 50T

Certification : ECE, GCC, CE, ISO9001, DOT, CCC, ISO/TS16949

Wheel Base : 8000-9000mm

Tread : 2240mm

Grade : Heavy Duty

Types of Suspension Systems : Multi-link Type

Shape : Flatbed

Axle Number : 3

Tire Number : 12

Self-dumping : Not Self-dumping

ABS Anti-lock Braking System : ABS Anti-lock Braking System

Material : Steel

Condition : New

Axle : Fuwa / BPW

Suspension : Leaf Spring Suspension

Kingpin : Jost 2" or 3.5"

Langing Gear : Jost

Twist Lock : 12

Tire : 12.00r20

Valve : Webco

Color : Customized

Payload : 40t

Transport Package : Nude Packing

Specification : 12.5 Meters

Trademark : FOCUS

Origin : China

HS Code : 8716391000

Production Capacity : 1500units Per Month

Contact Now

Enclosed Side Wall/Drop Side/Fence Utiltiy Truck Tractor Trailer for container and bulk cargo transport
Webco Enclosed Side Wall Utility Truck Trailer for Container and Bulk Cargo Transport
Webco Enclosed Side Wall Utility Truck Trailer for Container and Bulk Cargo Transport
Webco Enclosed Side Wall Utility Truck Trailer for Container and Bulk Cargo Transport
Item Unit Quantity Notice
Overall size 14500*2500mm
Detail according to confirmed drawing
Fence Set 1 0.6m height side board
Axle Piece 3 13 T axle,Widen brake pad 220mm
Tyre Piece 12 12R22.5-16PR, without spare tire
Rim Piece 12 9.0*22.5 Aluminum
Leaf spring Sets 6 90width*10 pieces*13mm thickness
Braking system Set 2 line air braking system with air tank ,emergency relay valve,braking chambers and mechanical slack adjusters.

Electrical system		 Set 1 24 volt electrical system.7 pin electrical, LED lights, connector.Parking .Stop,reverse,number plate and indicator lights.Rear lights conform to European standard,rear front and side reflectors
Suspension Set 3 Standard type
Relay valve Whole vehicle 1 WABCO
Landing gear Pair 1 Standard 16T, two-speed operation
Kingpin Piece 1 BAO HUA welded type, 90#
Chamber Piece Double T30/30 on rear two axles,T30 on 1st axle
Side beam 140# channel steel 2.5mm)

Floor		 1.6mm high-tensile steel plain plate
Cross beam Square tube 80*40
Upper and lower wing plates 10/10mm
Tool box 1 2.5m/1

Main beam		 Main beam500mm,webplate:5mm
Reflectors Red triangle reflectors at the rear of the trailer and on side
Shotblasting and paint Chassis is comletely shor blasted to SA 2.5 grade,and painted with first layer of international Zinc Epoxy primer(30 Microns DEF),second layer international high built polyurethane under coat(40 microns DFT),THIRD AND FORTH LAYERS INTERNATIONAL alkyd FINISH TOP coat.Total 80-100 microns.
High quality painting
Color According to your detail RAL code color
Webco Enclosed Side Wall Utility Truck Trailer for Container and Bulk Cargo TransportWebco Enclosed Side Wall Utility Truck Trailer for Container and Bulk Cargo Transport
Webco Enclosed Side Wall Utility Truck Trailer for Container and Bulk Cargo Transport
The dropside / sidewall trailer is for different kind of cargo long distance transportation, from boxes to bulk cargo. The side panel can be opened, more convenient to unload cargo. This trailers is widely used by transportation companies in the logistics industry. The shape of the side panel can be customized.
1-trailers can be for containers shipping, boxes, bags, steel bars, pipes, and other cargo transportation.
2-Axles number:2 3 4 axles even more.
3-Main beam:500mm height
4-material of the main beam:Q345
5-Suspension:Spring suspension, Rigid, single point, bogie or air suspension
6-Jost landing gear, FUWA axles and Tri-angle tires
7-extendable or sliding type optional

Our dropside trailers advantages:
**Modern design:Double-Groove vertical van, light-weight I beam, arched form longitudinal beams, that make the trailers
Structure super strong and superlight;
**Sound Adaptability:Passed the special processing, the overall frames of the traielrs can stand the actual test of various
Road conditions.
**Superior Material selection:The raw materials are bought from top 5 Steel Mills, and all of other parts are all from top
Suppliers also, like Triangle tyres, Jost landing gear, WEBCO relay valve, we have strict selection requirement for vendors.
**Top configurations:Ensure every trailers with high configurations to decrease the maintaince for clients, and improve the
Trailers with longer service time
Webco Enclosed Side Wall Utility Truck Trailer for Container and Bulk Cargo Transport
Webco Enclosed Side Wall Utility Truck Trailer for Container and Bulk Cargo Transport
Webco Enclosed Side Wall Utility Truck Trailer for Container and Bulk Cargo Transport
HENAN FOCUS VEHICLES Co., Ltd.(Short for Focus Vehicles), is commited to R&D, manufacturing, sales and services of high-end special vehicles.It has been gained good reputation and awarded with honors and titles, such as"HENAN High-tech enterprise", "Trustworthy Brand", "Being committed to supplying high quality equipment and service for urban logistics and transportation", etc.Our mission is to creat more value for clients, employees, partners and shareholds, determined to become a real enterprise being respected in China special vehicles inducstry.
Various of trailers we can provide and be manufactured as special design and with environment protection equipments, Flatbed Semi-trailer, Container Chassis, Low-bed Semi-trailer, Fuel tank Semi-trailer, Bulk Cement Tank Semi-trailer, Fence semi-trailer, Side wall Semi-trailer, Box semi-trailer, Dump Semi-trailer, LPG LNG semi-trailer, Full trailer, Dump truck, fuel tanker truck, water tanker truck, cargo truck, concrete mixturetruck etc with great price and service advantages.
Clients visit
Webco Enclosed Side Wall Utility Truck Trailer for Container and Bulk Cargo Transport
Webco Enclosed Side Wall Utility Truck Trailer for Container and Bulk Cargo Transport
1**You please send us your enquiry;
2**We shall reply you with the quotation within 12 hours;
3**We negotiate on the configuration that you need;
4**Confirmation of the tech data → sign contract (P/I) → 30% deposit (or L/C issuing)→ production;
5**Manufacturing process updated news → completing production;
6**Balance payment → ex works → shipment → custom clearance → A/S service for 1 year.

Service Promise
1.24-hours hot line at your service, available for quality and extending service.
2.Lifelong free technical guidance service can be provided.
3.For Customers who buy bulk quantity for the first time, we can send service technicians to offer site instruction service
And short- term stationary point service.
4.Free technical training can be provided to help customers use and maintain the trucks and trailers quickly and correctly.
